Description
Clinical and Accessories:
A stable base with comprehensive lateral trunk support encourages an upright, midline sitting posture. The lumbar position is fully adjustable, and stability wedges can be added to further enhance lateral contouring. The bubble contour foam pad design incorporates a unique “bubble” structure to improve immersion, redistribute pressure, and facilitate continuous airflow for enhanced comfort.
Standard Accessories included:
- Customisable
- Max User Weight: 136kg
- Product Weight (quick-release): 2.2kg (18×13)
- Pressure redistribution: High
- Composition: Aluminium Shell, Alloy & stainless steel hardware, high resilient cnc profile cut open cell urethane foam inner, overlaid with Sunmate visco-elastic foam with breather holes & a Flo2™ 4-way stretch breathable, moisture wicking outer cover.
- Covers: Flo2™ 4-way stretch breathable, moisture wicking outer cover.
- Other items Included in the pack: Lumbar Pad x 1, Lateral stability wedges x 2, mini positioning wedges x 2 & a pair of attachment Clamps.
- Contour Depth Profile (18″ – from centre front to front of laterals): 6″
- Adjustability: 3″ width, 3″ depth, 60˚ angle (+30˚ / -30˚)
- Sizes: 14″x 16″ – 20″x 20″
- Comes with mounting hardware
Size and Specifications:
| User Chest Width (“) | User Back Height (“) | Backrest Size (“) | Will fit Wheelchair Width(“) | Lateral Support Depth (“) | Will fit Backrest Tube Diameter (“) | Code |
| 11 | 16 | 14 x 16 | 12 up to 16 | 5 | Up to 1 | FGA1642 |
| 11 | 18 | 14 x 18 | 12 up to 16 | 5 | Up to 1 | FGA1643 |
| 12 | 17 | 15 x 16 | 13 up to 17 | 5 | Up to 1 | FGA1644 |
| 12 | 17 | 15 x 18 | 13 up to 17 | 5 | Up to 1 | FGA1645 |
| 13 | 18 | 16 x 18 | 14 up to 18 | 6 | Up to 1 | FGA1646 |
| 13 | 20 | 16 x 20 | 14 up to 18 | 6 | Up to 1 | FGA1647 |
| 14 | 18 | 17 x 18 | 15 up to 19 | 6 | Up to 1 | FGA1648 |
| 14 | 20 | 17 x 20 | 15 up to 19 | 6 | Up to 1 | FGA1649 |
| 15 | 20 | 18 x 18 | 16 up to 20 | 6 | Up to 1 | FGA1650 |
| 15 | 20 | 18 x 20 | 16 up to 20 | 6 | Up to 1 | FGA1651 |
| 17 | 18 | 20 x 18 | 18 up to 22 | 6 | Up to 1 | FGA1652 |
| 17 | 20 | 20 x 20 | 18 up to 22 | 6 | Up to 1 | FGA1661 |
Optional Accessories:
- BAC Positioning System
- Extra BAC Pads 10pk
- BAC Growth kit
- Interface Plate for Corpus Seating
- Spare outer breathable cover
- Extra hardware clamp set for 2nd mobility base
- 4 point mount hardware
- Dynamic Bracket kit
- Stability wedge and lumber pad kit
